Gas springs are standard parts used in stamping dies. They are composed of a body filled with nitrogen and a core plunger which reduces the inner volume under the pressure of the die. This system uses the compressibility of the gas to maintain a constant pressure on the stamped part.
With over 30 years of experience in the manufacture of gas springs, Quiri offers a full range of certified PED 2014/68/EU gas struts. Our gas shocks are renowned worldwide for their long lifetime and their one-piece conception which guarantees higher safety during use.
A nitrogen load balancer uses the compressibility of the gas to compensate the load of a mobile element.
HIGH POWER RGP GAS SPRINGS
Gas spring with body diameter 19 to 150 mm, force 170 to 9500 daN.
HIGH POWER RGT GAS SPRINGS
Compact gas spring with body diameter 50 to 150 mm, force 1000 to 9500 daN. Identical as RGP type but with thicker bottom for better fastening and linking.
LOW PROFILE RGH GAS SPRINGS
Gas spring with body diameter 45 to 120 mm, force 500 to 5000 daN.
ISO GAS SPRINGS
Gas spring with body diameter 38 to 165 mm, force 250 to 10000 daN.
MICRO MRG GAS SPRINGS
Gas spring with body diameter 25 mm, force 20 to 200 daN and stroke 7 to 125 mm.
MICRO RG19 GAS SPRINGS
Gas spring with body diameter 19 mm, force 22,5 to 90 daN and stroke 7 to 125 mm.
MICRO RG300F GAS SPRINGS
Gas spring with threaded body M38x1.5, force 300 daN and stroke 10 to 100 mm.
MICRO RG32 GAS SPRINGS
Gas spring with body diameter 32 mm, force 50 to 200 daN and stroke 10 to 125 mm.
MICRO RMG GAS SPRINGS
Gas spring with body diameter 25 mm, force 50 to 200 daN and stroke 10 to 125 mm.
MICRO RMGE GAS SPRINGS
Gas spring with body diameter 25 mm, force 50 to 200 daN and stroke 10 to 125 mm.
MICRO RMGT GAS SPRINGS
Gas spring with body diameter 25 mm, force 50 to 200 daN and stroke 10 to 125 mm.
SUPER COMPACT RGC
Gas spring with body diameter 25 to 150 mm, force 420 to 18300 daN.
