TOOLS
TOOLKIT FOR DISASSEMBLING – 082078000
Full equipment for gas spring disassembling.
Including sleeve, threaded bar, tools and valves.
EXTRACTION HANDLE
| Type | Order codes |
| M6 | A95031 |
| M8 | A95032 |
This handle, screwed on the end of piston rod, facilitates the extraction of the piston rod + guide ring from the gas spring body.
STOP RING DISMOUNTING TOOL
| Size | Order codes |
| 1 | 082078/100 |
| 2 | 082078/200 |
Always wear safety glasses while dismounting the stop ring.
VALVE ASSEMBLING AND DEFLATING TOOL AND VALVES
| Type of gas spring | Tool order codes | Valve |
| RG 19 | 081071/000 + 081055/000 | A99926 |
| MRG | 081071/000 + 081055/000 | A99926 |
| RMG/T/E | 081053/000 | A99135 |
| RG 32 | 081071/000 + 081055/000 | A99926 |
| RG 300 F | 081053/000 | A99135 |
| RGP 170 à RGP 1000 | 081071/000 + 081055/000 | A99926 |
| RGP 1500 à RGP 2400 | 081055/000 | A99135 |
| RGP 4200 à RGP 9500 | 081041/000 | A99135 |
| RGT 1000 | 081071/000 + 081041/000 | A99926 |
| RGT 2400 à RGT 9500 | 081041/000 | A99135 |
| RGC 420 et RGC 750 | 081071/000 + 081055/000 | A99926 |
| RGC 1000 à RGC 3000 | 081055/000 | A99135 |
| RGC 4700 à RGC 18300 | 081041/000 | A99135 |
| RGH | 081055/000 | A99135 |
| RG 250 | 081071/000 + 081041/000 | A99926 |
| RG 500 C10 à C100 | 081041/000 | A99135 |
| RG 500 C125 à C160 | 081071/000 + 081055/000 | A99926 |
| RG 750 C13 à C160 | 081041/000 | A99135 |
| RG 750 C200 à C300 | 081071/000 + 081055/000 | A99926 |
| RG 1500 à RG 10000 | 081041/000 | A99135 |
