Hydraulic hand pumps 700 bar

Steel hand pumps :

• Working pressure 700 bar.
• 1 speed pumps : 2,5 cm3 / pump stroke
• 2 speeds pumps :
    – LP = 19 cm3 / pump stroke until 15 bar
    – HP = 2,5 cm3 / pump stroke until 700 bar
• Tanks from 0,4L to 12L (depends on models)
• 3/8″ NPT oil port

Different types of hand pumps available :

• Hand pumps PMS 7104-710-712 : 1 speed, for single acting cylinders
• Hand pumps PMS 733-736-7312 : 2 speeds, for single acting cylinders
• Hand pumps PMD 733-736-7312 : 2 speeds, for double acting cylinders

Light alloy hand pumps :

• Working pressure 700 bar.
• 2 speeds pumps :
  – LP = 12 cm3 / pump stroke until 80 bar
  – HP = 1,94 cm3 / pump stroke until 700 bar
• Tanks capacity : 1L, 1,5L, 3L and 6L
• G1/4″ oil port

Different types of hand pumps available :

• Hand pumps QSH : 2 speeds, for single acting cylinders
• Hand pumps QDH : 2 speeds, for double acting cylinders
