Single acting hand pumps, 1 and 2 speeds – 700 bar

For single acting cylinders

Features

• 1 speed (BK – 05)
• 2 speeds (BKD – 09)
• External adjustable pressure relief valve, set at 700 bar
• Delivered with oil

Options

Other relief valve setting : on request

Print this sheet
Single acting hand pumps, 1 and 2 speeds – 700 bar : Hydraulic hand pumps 700 bar - Quiri - 2
Pressure Oil flow Pressure Oil flow Oil capacity Maxi. handle effort Reference Dimensions (mm) Weight
a b c d e f g
bar cm3/pump stroke bar cm3/pump stroke Total Usable kg
LP HP cm3 cm3 daN
20 12,9 700 1,65 500 350 65 PAM 7203 390 125 127 110 77 113 359 3,6
20 12,9 700 2,3 2000 1620 58 PAM 722 615 135 135 150 102 138 549 6,5

Product accessories

ø 100 pressure gauge adaptor – 700 bar – AM 135

ø 100 pressure gauge – 700 bar

Standard Thermoplastic hoses (internal Ø 6mm) – 700 bar

Internal 6mm
