COMPACT CONTROL UNITS

• FEMALE G1/8’’ THREAD ADAPTER | QNCB-A – (834959/000)
• FAST COUPLING ADAPTER (STAUBLI standard) | QNCB-B – (834957/000)
• FAST COUPLING ADAPTER (CEJN standard) | QNCB-C – (834960/000)
• FAST COUPLING ADAPTER (CEJN standard, special fixture) | QNCB-T – (834964/000)

• OPTION : Adjustable pressure switch 50-150 bar for control block QNCB – (A68688)

A maximum of 4 QTP adapters can be fitted on the control panel, we set up 2 pieces.

Please use plyer to adjust the outlet valve, the mounting torque should be less than 30 N.m. The force must be less than 10 kg. There can be some useless oil coming out with nitrogen when you open the outlet valve in piping system.

WARNING : Please pay attention to not let the oil go into your eyes.
