Single acting hand pumps, 1 speed – 700 bar – PMS

For single acting cylinders

Features

• 1 speed
• External adjustable pressure relief valve, set at 700 bar
• Delivered with oil
• Carrying handles on PMS 710 and PMS 712

Options

Other relief valve setting : on request
2 x M6 fixing holes

Print this sheet
Single acting hand pumps, 1 speed – 700 bar – PMS : Hydraulic hand pumps 700 bar - Quiri - 2
Max pressure Oil flow Oil capacity Max handle effort Reference Dimensions (mm) Weight
a b c d e f g
Total Usable
bar cm3/pump stroke cm3 cm3 daN kg
700 3.2 750 500 60 PMS 7105 543 157 145 110 134 90 495 7

Product accessories

ø 100 pressure gauge adaptor – 700 bar – AM 135

ø 100 pressure gauge – 700 bar

Standard Thermoplastic hoses (internal Ø 6mm) – 700 bar

Internal 6mm
