CONNECTION WITH CONNECTOR

Print this sheet

CN 11/CN12/CN15 WITH STRAIGHT CONNECTOR

CONNECTION WITH CONNECTOR : CONNECTIONS FOR ISO GAS SPRINGS - Quiri
CONNECTION WITH CONNECTOR : CONNECTIONS FOR ISO GAS SPRINGS - Quiri - 2
Type A B H Jmin.
RGR 500 24.5 64.5 10.1 128
RGR 750 23 53 129
RGR 1500 142
RGR 3000 11 152
RGR 5000 164
RGR 7500 12.5 179
RGR 10000 187



CN 11/CN12/CN15 WITH 90° ELBOW CONNECTOR

CONNECTION WITH CONNECTOR : CONNECTIONS FOR ISO GAS SPRINGS - Quiri - 3
CONNECTION WITH CONNECTOR : CONNECTIONS FOR ISO GAS SPRINGS - Quiri - 4
Type C D H
RGR 500 36.5 47.5 10.1
RGR 750 34 46
RGR 1500
RGR 3000 11
RGR 5000
RGR 7500 12.5
RGR 10000
