MINI MANIFOLD BLOCK

Print this sheet

MINI MANIFOLD BLOCK QMMB FOR CN 14 – (834924/000)

MINI MANIFOLD BLOCK : CONNECTIONS FOR ISO GAS SPRINGS - Quiri

Type	H	H1	H2
RGR 500	10.1	26.6	1.6
RGR 750
RGR 1500
RGR 3000	11	27.5	2.5
RGR 5000
RGR 7500	12.5	29.0	4.0
RGR 10000
