CONNECTION WITH CONNECTOR

Print this sheet

CN 11 WITH STRAIGHT CONNECTOR

CONNECTION WITH CONNECTOR : CONNECTIONS FOR RGH GAS SPRINGS - Quiri

CN 11 WITH 90° ELBOW CONNECTOR

CONNECTION WITH CONNECTOR : CONNECTIONS FOR RGH GAS SPRINGS - Quiri - 2
Type Jmin.

(mm)
RGHR 500 147.5
RGHR 750 150
RGHR 1500 162.5
RGHR 3000 172.5
RGHR 5000 185



View similar products

MINI MANIFOLD BLOCK
