Hydraulic block cylinders BDD Guide

Print this guide

Quick access to sections

Designation

Designation

Test pressure: 500 bars
Max working pressure: 350 bars

Hydraulic block cylinders BDD Guide : Hydraulic block cylinders BDD - Quiri

Code example: BDD 100-25 V P T
Double acting block cylinder, bore 50 mm, stroke 25 mm, Viton® seals, fixing holes parallel to the rod, tapped ports, tapped rod.

OPTION : STROKE REDUCTION

Possibility to add a stroke reduction.
Code example: BDD 100-25 V P T S C20
Cylinder with an outside size of a stroke 25mm but the stroke is limited to 20mm.
