Hydraulic block cylinders BDE Guide

Print this guide

Accès rapide aux sections

Designation
BDE improvements

BDE Designation

Hydraulic block cylinders BDE Guide : Hydraulic block cylinders BDE - Quiri

Order code example: BDE 63.150 V F4 F H80 X120 PU LI
Steel block cylinder , double acting, improved guiding, bore 63 mm, stroke 150 mm, Viton® seals, fixture and feeding F4 type, key groove, 80 mm, rear fixation at 12 mm, venting port, smooth fixing holes.

BDE improvements

1 : Guiding improvement for heavy duty – Lowering of leakage risk, life time improvement

Hydraulic block cylinders BDE Guide : Hydraulic block cylinders BDE - Quiri - 2

2 : Feeding seal in closed grooves and counterbores on all fixing holes

Hydraulic block cylinders BDE Guide : Hydraulic block cylinders BDE - Quiri - 3

3 : New model: F4 with keyway position on demand.

Cheaper
More compact
Feeding in the same plan

Hydraulic block cylinders BDE Guide : Hydraulic block cylinders BDE - Quiri - 4

4 : High temperature seals: Up to 200°C (392°F).

(For temperature higher than 150°C (302°F), please contact us)
