Dimensions and installation

Mounting accessories for 350V series cylinders : 350 bar hydraulic cylinders - Quiri

Trunnion plate

Bore Dimensions Reference
 a f8 b c d e f g h j k l m x
40 28 25 82 132 30 14 M48 x 1.5 52 80 64 M 8 6 87 811028
50 32 25 102 152 34 14 M58 x 1.5 62 100 80 M 10 6 95 812058
63 40 32 120 184 42 19 M74 x 1.5 78 118 98 M 10 8 110 812060
80 50 40 142 222 52 25 M94 x 2 98 140 118 M 12 8 136 812062
100 60 48 174 270 62 30 M118 x 2 125 170 144 M 14 8 170 813039
125 75 60 216 336 77 38 M148 x 2 154 212 184 M 16 10 203 813041
140 85 68 240 376 87 46 M166 x 2 174 236 202 M 18 10 225 814029

Front flange

Bore Dimensions Reference
 i n o q r S e 9 t v w y
40 14 6 11 105 130 48 64 M 8 6 19 811029
50 16 6 14 130 160 58 80 M 10 6 21 812059
63 20 8 14 150 180 76 98 M 10 8 26 812061
80 22 8 16 175 205 92 118 M 12 8 33 812063
100 26 10 18 205 240 115 144 M 14 8 38 813040
125 32 10 22 255 300 150 184 M 16 10 49 813042
140 35 12 22 280 320 166 202 M 18 10 55 814030
Mounting accessories for 350V series cylinders : 350 bar hydraulic cylinders - Quiri - 2

Front endeye

Bore Thread K Dimensions Reference
S e u a b c d f x y
40 M18 x 1.5 35 25 20 80 55 22 27 28 222 247 811030
50 M22 x 1.5 42 30 24 98 68 26 33 36 250 280 812064
63 M27 x 2 55 38 30 123 85 34 40 44 290 328 812065
80 M33 x 2 68 48 38 153 104 42 48 54 342 390 812066
100 M42 x 2 90 61 50 185 124 52 58 68 412 473 813043
125 M56 x 2 105 75 58 230 155 67 78 86 490 565 813044
140 M64 x 3 120 85 64 265 180 75 90 98 550 635 814031

Ball joint and snap rings

Bore Ø S

(M7)

 Dimensions References
h i alpha Ball joint Snap rings
40 35 20 16 9 A68012 AQ2033
50 42 25 20 7 A68043 AQ2035
63 55 35 25 6 A68044 AQ2054
80 68 45 32 7 A68045 AQ2059
100 90 60 44 6 A68016 AQ2077
125 105 70 49 6 A68047 AQ2089
140 120 80 55 6 A68017 AQ2079
