Hollow piston single acting cylinders – Load return – QUIRI 700 – Light alloy – 700 bar

QCG

Features
Notes

Features

Single acting, load return
Body and stem in anodized light alloy
Supplied with hollow saddle
Supplied as standard with HF 738 coupler

Notes

Supplied with 4 threaded mounting holes.
Equipped with double handling handles from QCG 40/50 upwards.
Supplied with 2xM10 threaded holes in order to use lifting rings from QCG 100/50.

Print this sheet

Hollow piston single acting cylinders – Load return – QUIRI 700 – Light alloy – 700 bar : Lifting light alloy cylinders 700 bar - Quiri - 2

Cylinder category	Maximum force at 700 bar	Stroke	Effective area	Oil volume	Reference	Dimensions										Mass
Tons	kN	mm	cm²	cm³	Reference	a	b	d	h	i	j	k	n	q	M x p on øg	kg
20	221	51	31.62	161.262	QCG 20/50	75	187	102	21	65	55	52	2.1	27	4xM6x12 sur ø80	4.1
		101		319.362	QCG 20/100		237									5.1
		151		477.462	QCG 20/150		287									6
40	395	51	56.5	288.15	QCG 40/50	110	208	148	31	65	85	80	3	50	4xM6x12 sur ø110	9.8
		101		570.65	QCG 40/100		258									11.9
		151		853.15	QCG 40/150		308									13.7
60	620	51	88.5	451.35	QCG 60/50	130	245	180	36	65	95	90	3	54	4xM6x18 sur ø160	17
		101		893.85	QCG 60/100		295									19.7
		151		1336.35	QCG 60/150		345									22.7
100	1116	51	159.4	812.94	QCG 100/50	180	257	250	47	65	135	130	2	79	4xM6x12 sur ø220	34.5
		101		1609.94	QCG 100/100		307									40.2
		151		2406.94	QCG 100/150		357									45.8
