Hollow piston single acting cylinders – Spring return – QUIRI 700 – Light alloy – 700 bar

QCR

Features
Notes

Features

Single acting, spring return
Body and stem in anodized light alloy
Supplied with hollow saddle
Supplied as standard with HF 738 coupler

Notes

Supplied with 4 threaded mounting holes.
Equipped with double handling handles from QCR 40/50 upwards.
Supplied with 2xM10 threaded holes in order to use lifting rings from QCR 100/50.

Print this sheet

Hollow piston single acting cylinders – Spring return – QUIRI 700 – Light alloy – 700 bar : Lifting light alloy cylinders 700 bar - Quiri - 2

Cylinder category	Maximum force at 700 bar	Stroke	Effective area	Oil volume	Reference	Dimensions										Mass
Tons	kN	mm	cm²	cm³	Reference	a	b	d	h	i	j	k	n	q	M x p on øg	kg
20	221	50	31.62	158.1	QCR 20/50	75	187	102	21	65	55	52	2.1	27	4xM6x12 sur ø80	4.4
		100		316.2	QCR 20/100		237									5.3
		150		474.3	QCR 20/150		287									6.2
40	395	50	56.5	282.5	QCR 40/50	110	208	148	31	65	85	80	3	50	4xM6x12 sur ø110	10.3
		100		565	QCR 40/100		258									12.4
		150		847.5	QCR 40/150		308									14.5
60	620	50	88.5	442.5	QCR 60/50	130	245	180	36	65	95	90	3	54	4xM6x18 sur ø160	17.9
		100		885	QCR 60/100		295									20.7
		150		1327.5	QCR 60/150		345									23.8
100	1116	50	159.4	797	QCR 100/50	180	257	250	47	65	135	130	2	79	4xM6x12 sur ø220	36
		100		1594	QCR 100/100		307									41.7
		150		2391	QCR 100/150		357									47.3
