Battery-operated pumps – For single-acting cylinders – 700 bar – PHB

Features

2-stroke piston pump: For use with short-stroke cylinders (25mm maxi).

  • LP: 0.7l/min at 20 bar
  • HP: 0.06l/min at 700 bar
  • Supplied with 4A lithium battery + charger
  • Adjustable safety valve, set to 700 bar
  • Compact design with ergonomic handle and shoulder strap for maximum portability
  • Pump can be used horizontally and vertically
  • Oil capacities: 1l and 5l

Nota

Accessories can be ordered separately.

Print this sheet
Battery-operated pumps – For single-acting cylinders – 700 bar – PHB : Battery-operated pumps - Quiri - 2
Pressure Oil flow Max Pressure Oil flow Oil capacity Battery Reference Oil outlet Dimensions (mm) Weight
a b c d e f g
bar l/min bar l/min Total Usable
BP HP cm3 cm3 kg
20 0.7 700 0.06 1000 1000 Lithium DC 14.4V – 4Ah PHB 712 3/8′ ‘ NPT 102 292 168 43 122 108 55 5
20 0.7 700 0.06 5000 4500 Lithium DC 14.4V – 4Ah PHB 752 3/8′ ‘ NPT 300 350 145 43 – – 35 25

Product accessories

Battery for PHB pumps

Battery charger for PHB pumps
