Hydraulic block cylinders – BDS
Test pressure: 500 bars
Max working pressure: 350 bars
Key provided
- Double stem seal
- Galvanized one-piece body
- Treated one-piece piston rod
- Strokes ± 0.3mm
- 2-year or 400 km warranty (4 million cycles for a 50 mm stroke)
| TYPE | Units | BDS 25 | BDS 32 | BDS 40 | BDS 50 | BDS 63 | BDS 80 | BDS 100 | BDS 125 |
| Piston | (mm) | 25 | 32 | 40 | 50 | 63 | 80 | 100 | 125 |
| Rod | (mm) | 16 | 18 | 22 | 28 | 36 | 45 | 56 | 70 |
| Pushing force at 100 bars | (kN) | 4.9 | 8.0 | 12.5 | 19.6 | 31.1 | 50.2 | 78.5 | 122.6 |
| Pulling force at 100 bars | (kN) | 2.8 | 5.5 | 8.7 | 13.4 | 21 | 34.3 | 53.8 | 84.1 |
| a | (mm) | 60 | 75 | 90 | 100 | 120 | 150 | 170 | 200 |
| b | (mm) | 50 | 66 | 76 | 86 | 106 | 130 | 155 | 182 |
| c | (mm) | 7 | 8 | 10 | 10 | 12 | 14 | 14 | 15 |
| e | (mm) | 23 | 29 | 34 | 35 | 42 | 44 | 48 | 56 |
| f | (mm) | 46 | 62 | 72 | 82 | 98 | 126 | 146 | 170 |
| g | (mm) | 6.5 | 9 | 11 | 11 | 13 | 13 | 15 | 17 |
| g1 x depth | (mm) | ø11 x 6.5 | ø14 x 9 | ø17 x 11 | ø17 x 11 | ø19 x 13 | ø19 x 13 | ø22 x 15 | ø25 x 17 |
| h mini | (mm) | 43 | 53 | 60 | 60 | 72 | 76 | 87 | 97 |
| h maxi | (mm) | h mini + stroke | |||||||
| j H8 | (mm) | 6 | 8 | 8 | 10 | 12 | 16 | 16 | 20 |
| L(“S”) | (mm) | 66 | 82(76) | 95(85) | 95 | 118(108) | 125(126) | 140 | 165 |
| L1 (damping A1) | (mm) | 82 | 94 | 102 | 116 | 130 | 152 | – | – |
| L2 (damping A2) | (mm) | 79 | 90 | 103 | 120 | 129 | 150 | – | – |
| L3 (damping A1+A2) | (mm) | 95 | 108 | 120 | 141 | 151 | 176 | – | – |
| LI | (mm) | 81 | 97 | 110 | 110 | 133 | 140 | 155 | 180 |
| k | (mm) | 26 | 38 | 45 | 50 | 60 | 70 | 85 | 100 |
| v | (mm) | 5 | 8 | 10 | 10 | 12 | 14 | 14 | 14 |
| w x depth | (mm) | ø12.7 x 1.4 | ø15.9 x 1.4 | ø20.5 x 2 | ø20.5 x 2 | ø22.3 x 2 | ø23.8 x 2 | ø23.8 x 2 | ø23.8 x 2 |
| z | (mm) | 4 | 5 | 5 | 5 | 5 | 5 | 5 | 5 |
| z’ (+0.1 0) | (mm) | 4 | 5 | 5 | 5 | 5 | 5 | 5 | 5 |
| X (stroke > 130mm) | (mm) | By choice | |||||||
| 3D Model (Without information rod) | 3D | 3D | 3D | 3D | 3D | 3D | 3D | 3D | |
| 3D Model (With information rod) | 3D | 3D | 3D | 3D | 3D | 3D | 3D | 3D | |
Rod ends
| TYPE | Units | BDS 25 | BDS 32 | BDS 40 | BDS 50 | BDS 63 | BDS 80 | BDS 100 | BDS 125 |
| ød | (mm) | 16 | 18 | 22 | 28 | 36 | 45 | 56 | 70 |
| A | (mm) | 20 | 20 | 25 | 30 | 40 | 50 | 60 | 70 |
| B | (mm) | 5 | 6 | 8 | 8 | 10 | 12 | 12 | 13 |
| M | (mm) | M12 x 125 | M12 x 125 | M16 x 150 | M20 x 150 | M27 x 200 | M33 x 200 | M42 x 200 | M52 x 200 |
| C | (mm) | M8 x 125 | M8 x 125 | M10 x 150 | M16 x 150 | M20 x 150 | M27 x 200 | M33 x 200 | M42 x 200 |
| K | (mm) | 12 | 14 | 17 | 22 | 30 | 36 | 46 | 60 |
