Hydraulic Clamping Systems

A full range of swing cylinders, work-holding cylinders, applicator cylinders etc. specially designed for the clamping of mechanical parts in automated machining units. Constant innovation and high product quality have resulted in rapid acceptance by the automotive and aeronautical industry.

Products

Infos

Hydraulic work supports

Hydraulic work supports are used to support the workpieces in a specific plan and prevent vibration during machining.

Infos

Linear cylinders

Single or double acting, the linear cylinder is mainly used for holding a workpiece against its isostatic references before sarting the clamping process. This range can also be used for internal movements in plastic injection molds.

Infos

Positive locking cylinders

T-Lock (translation) and R-Lock (rotation) cylinders developed and patented by QUIRI, incorporate a system based on the principle of locking through the absence of pressure. Unlocking is achieved by the use of a pressurised fluid.

Infos

Stainless steel swing clamps with helical rotation

The stainless steel swing clamps with helical rotation are dedicated to challenging environment. The design of this cylinders allows the use of borated or demineralized water, eliminating any risk of pollution of a clean medium.

Infos

Swing clamps with helical rotation

The swing clamps can clear the working area to facilitate components loading and un-loading operations. Designed for self-controled systems, they reduce non-productive time.

Infos

Swing clamps with planar rotation

The swing clamps can clear the working area to facilitate components loading and un-loading operations. Designed for self-controled systems, they reduce non-productive time.

Infos

Swing clamps with position detection

The swing clamps with planar or helical rotation can be designed with different solutions of position detections. The system can detect the released position only or the 2 extreme positions of the cylinder.

Zero Point Clamping System

QUIRI ZERO POINT design is made up of a patented collet clamping system, and thanks to surface contacts, it offers many advantages. The clearance in the presentation of the elements to be clamped, allows quick and efficient installation and removal of assembly fixtures and parts.

As a specialist of the design and manufacture of hydraulic equipment, Quiri Hydromechanics offers a full range of hydraulic clamping systems, positive locking and linear cylinders, swing clamps, work supports and zero point systems, intended for the clamping of mechanical parts in process and manufacturing machine tools.

Robust and powerful, our hydraulic clamping cylinders and workholding devices can be adapted to a wide variety of machines and offer many possibilities in terms of combination. Set up on new or existing equipment, they allow the optimization of the machines adjustment time, whatever their size or manufacturer.

Most of our hydraulic clamping unit parts are available in different versions (e.g. single or double-acting cylinders) and allow us to provide you with the most sophisticated technology, adapted to the needs of your industry.

Mastering every skill related to industrial hydraulics and thanks to important research and development efforts, Quiri Hydromechanics is ISO 9001 certified and is able to provide you with the most innovative and efficient components (zero point clamping system, rotary clamp cylinders, hydraulic cylinders with position sensors…) or complete clamping systems.
