Corner clamping element KSM-P

Double-acting with position control
Clamping force 25kN to 630 kN

Field of application

Corner clamping elements make it possible to fasten a fixture safely and hold it when there is no pressure. These elements are mainly used for clamping press tools or machining fixtures.

Description

A guiding element is screwed to a double-acting block clamp.
Clamping is maintained thanks to the slope of the end of the rod, by wedging

Characteristics

• 20 to 40 mm travel
• clamping force up to 630 kN
• compact size
• max. service pressure 275/350 bar
• hardened steel rod
• version with position control

Print this sheet

Important recommendations

Due to the shearing forces that occur during corner clamping, the tools must be secured to prevent movement, for instance using positioning pins or mechanical stops.
The elements must be protected from the entry of dust, chips, coolant, etc.
The locking rod must be greased at regular intervals, when the rod is retracted.
Caution: in the event of an operating error, the rod may retract fully and the tool would fall.

Technical data of sensors

Output function: NO
Connection: PNP
Minimum sensing distance: 13 mm
Service temperature: -25° C to +70° C
Supply voltage: 10 to 30 VDC
Max. residual ripple 15%
Nominal usage current: 200 mA
Nominal range (Sn): 1.5 mm
Protected from short circuits
Stainless steel housing
DIN 40050 IP 67.. protection

Corner clamping element KSM-P : Linear cylinders - Quiri - 2
Thrust force

max

 Retaining force (8.8 screw) Pressure

max

 Travel



max

 Rod



øD

 Type Reference
a



 b



 c



 d



 e



 f



 g



 h



 i



 k



 l



 L1



 L2



 m



 n



 o



ø H7 x Depth

 p

±0.02

for øo

 q



 r



 s


kN kN bar mm mm mm mm mm mm mm mm mm mm mm mm mm mm mm mm mm mm mm mm mm
25 35 350 20 25 KSM-P-025 M 531-1-025 65 45 20 30 70 48 13 19.5 15 21.5 58 134 169 76 111 18 x 7 G1/4 48 14 38
50 65 275 25 40 KSM-P-040 M 531-1-040 85 63 25 40 95 65 17 23.5 18 28 78 168 211 102 146 26 x 9 G1/4 65 16 46
100 130 350 25 50 KSM-P-050 M 531-1-050 100 75 26 55 120 80 21 30.5 25 37 100 200 245 127 177 30 x 11 G1/4 85 20 58
160 210 350 30 63 KSM-P-063 M 531-1-063 125 95 32 70 150 105 26 37 30 49 125 235 280 151 210 35 x 11 G1/2 106 25 75
250 320 350 32 80 KSM-P-080 M 531-1-080 160 120 40 80 200 125 33 38 30 55 150 270 325 184 246 48 x 13 G1/2 140 26 78
400 520 350 40 100 KSM-P-100 M 531-1-100 200 150 45 100 240 160 39 60 50 75 180 310 365 215 285 55 x 16 G1/2 180 32 95
630 820 350 40 125 KSM-P-125 M 531-1-125 230 180 50 125 280 190 45 70 60 85 225 375 430 272 344 62 x 16 G1/2 210 38 108
