Single acting 1000 bar hand pumps, 2 speeds (SA25 + 8) – SA

For single acting cylinders

Single acting 1000 bar hand pumps, 2 speeds (SA25 + 8) – SA : Hydraulic hand pumps 1000 bar - Quiri

Features
Options

Features

• 2 automatic speeds
• Pressure relief valve, set at 1000 bar
• Delivered with oil

Options

• Other relief valve setting : on request
• M6 fixing holes

Print this sheet

Single acting 1000 bar hand pumps, 2 speeds (SA25 + 8) – SA : Hydraulic hand pumps 1000 bar - Quiri - 2

Pressure	Oil flow	Maximum pressure	Oil flow	Oil capacity		Maxi. handle effort daN	Reference *	Dimensions (mm)											Weight
								a	b	c	d	e	f	f ’	g	h	j
bar	cm3/pump stroke	bar	cm3/pump stroke	Total	Usable														kg
LP		HP		cm3	cm3
80	11	1000	1,13	1900	1500	30	SA25+8 R1,5	653	76	80	117	117	225	590	42	27,5	38	31	9
				6900	6000	30	SA25+8 R6	633	140	80	117	117	225	590	42	27,5	38	31	16
				12500	10000	30	SA25+8 R10	633	250	80	117	117	225	590	42	27,5	38	31	23

* Warning : To use this pump, it must be fitted with its accessories : block, adaptor, pressure gauge and hose (see below).

HOSES WITH COUPLERS

Single acting 1000 bar hand pumps, 2 speeds (SA25 + 8) – SA : Hydraulic hand pumps 1000 bar - Quiri - 3

Standard length *	Reference
1	A38055
2	A38056
3	A38057

* Other length on request

BLOCKS – PRESSURE GAUGES – ADAPTORS

Blocks
Nbr of outlets	Reference
1	MF31
2	MF32
3	MF33

Pressure gauges + adaptors
Size	References
ø 63	MG 0100 + AM 014
ø 150	MG 1600 + AM 112

View similar products

Single acting 1000 bar hand pumps, 2 speeds – PMS

For single acting cylinders
