RMG gas spring
Diameter : 25
| Type | Force | Stroke C | Reference | Pressure | Force F1 | Force F2 | LR | LC | Color | 3D Model |
| daN | mm | MPa (bar) | N * | N * | mm | mm | ||||
| RMG | 50 | 10 | 442061/000 | 4.5
(45) |
510 | 660 | 65 | 55 | green | 3D |
| 16 | 442062/000 | 690 | 77 | 61 | 3D | |||||
| 25 | 442063/000 | 720 | 95 | 70 | 3D | |||||
| 38 | 442066/000 | 720 | 121 | 83 | 3D | |||||
| 50 | 442064/000 | 720 | 145 | 95 | 3D | |||||
| 63 | 442067/000 | 720 | 171 | 108 | 3D | |||||
| 80 | 442065/000 | 730 | 205 | 125 | 3D | |||||
| 100 | 442068/000 | 720 | 245 | 145 | 3D | |||||
| 125 | 442069/000 | 720 | 295 | 170 | 3D | |||||
| 100 | 10 | 442071/000 | 9
(90) |
1 020 | 1 320 | 65 | 55 | blue | 3D | |
| 16 | 442072/000 | 1 380 | 77 | 61 | 3D | |||||
| 25 | 442073/000 | 1 430 | 95 | 70 | 3D | |||||
| 38 | 442076/000 | 1 430 | 121 | 83 | 3D | |||||
| 50 | 442074/000 | 1 430 | 145 | 95 | 3D | |||||
| 63 | 442077/000 | 1 430 | 171 | 108 | 3D | |||||
| 80 | 442075/000 | 1 450 | 205 | 125 | 3D | |||||
| 100 | 442078/000 | 1 440 | 245 | 145 | 3D | |||||
| 125 | 442079/000 | 1 440 | 295 | 170 | 3D | |||||
| 150 | 10 | 442081/000 | 13.5
(135) |
1 530 | 1 980 | 65 | 55 | red | 3D | |
| 16 | 442082/000 | 2 070 | 77 | 61 | 3D | |||||
| 25 | 442083/000 | 2 140 | 95 | 70 | 3D | |||||
| 38 | 442086/000 | 2 150 | 121 | 83 | 3D | |||||
| 50 | 442084/000 | 2 140 | 145 | 95 | 3D | |||||
| 63 | 442087/000 | 2 140 | 171 | 108 | 3D | |||||
| 80 | 442085/000 | 2 170 | 205 | 125 | 3D | |||||
| 100 | 442088/000 | 2 160 | 245 | 145 | 3D | |||||
| 125 | 442089/000 | 2 160 | 295 | 170 | 3D | |||||
| 200 | 10 | 442091/000 | 18
(180) |
2 040 | 2 640 | 65 | 55 | yellow | 3D | |
| 16 | 442092/000 | 2 760 | 77 | 61 | 3D | |||||
| 25 | 442093/000 | 2 850 | 95 | 70 | 3D | |||||
| 38 | 442096/000 | 2 860 | 121 | 83 | 3D | |||||
| 50 | 442094/000 | 2 850 | 145 | 95 | 3D | |||||
| 63 | 442097/000 | 2 860 | 171 | 108 | 3D | |||||
| 80 | 442095/000 | 2 890 | 205 | 125 | 3D | |||||
| 100 | 442098/000 | 2 880 | 245 | 145 | 3D | |||||
| 125 | 442099/000 | 2 870 | 295 | 170 | 3D |
* (N) = Kgf x 9.80665 | (Kgf)=N x 0.101972 | 1daN=1 x 101N | 1bar=1 x 10-1MPa
Example of order : RMG 100 C50
Spare kit : Not repairable.
