DM3 HT magnetic sensor
- Supply voltage : 10 to 30 V DC
- Permanent current : 200 mA at 25°C
- Connection : PNP-NO, connecteur M8
- Protection degree : IP 67 selon CEI 60529
- Temperature : -20°C to 105°C
- Cables : available on request
- Attachment through the clamp with position memory (sensor is provided).
Connection
Dimensions
Clamp
This clamp is used to fix sensor type DM3 HT.
It can be ordered separately or with the sensor.
It includes a small CHC screw, and allows position memorizing of the sensor.
Once it is setup in the right position, the replacement sensor will keep the same position.
