Swing cable with helical rotation – 250 bar – Pneumatic sensing of released position HL**XB1

Double-acting - with helical rotation - pneumatic position sensing
Force at 250 bar: 7.5 to 36.5 kN

Supply through counter-bores under the flange ring

Swing cable with helical rotation – 250 bar – Pneumatic sensing of released position HL**XB1 : Swing clamps with position detection - Quiri

Characteristics

• 8 to 12 mm travel
• right or left helical rotation, 90°±2°
• bleeder on clamping side
• rod indexing
• maximum service pressure: 250 bar
• detection by leak-free valves.
Clamped and released positions on clamp base, adjustable by screws

Options

• clamping arm: see accessories section
• 60°, 45° or 0° rotation on request

Nota

The clamps are supplied with O-rings, lock nut and lock washer (dimensions: see Lock washer for clamp type P11, P21 and Nut for clamp type P31 and P41)
O-rings:

5.28 x 1.78 90 NBR for HL12 and HL21
7.65 x 1.78 90 NBR for HL31 and HL41

Print this sheet

Swing cable with helical rotation – 250 bar – Pneumatic sensing of released position HL**XB1 : Swing clamps with position detection - Quiri - 2

Definition of forces depending on clamping arm: see below
Important recommendations: consult the guide

F max at 250 bar	Rod ød	Travel of torque	Travel total	Max flow rate A	Swept volume A B	Direction of rotation	Type	Reference
F max at 250 bar	Rod ød	Travel of torque	Travel total	Max flow rate A	Swept volume A B	Direction of rotation	Type	Reference	a	b	øD	ød	e	f span-ner	h	øk1 øk2	L1	L2	L3	øm	øp1	øp2	p3
kN	mm	mm	mm	l/min	cm³				mm	mm	mm	mm		mm	mm	mm	mm	mm	mm	mm	mm	mm	mm
7.5	12	11	23	0.4	6.95	right	HL 12 DX B1	191 258/050	14	10	45	20	M14 x 1.5	6	23	68	72	128	22	8.8	6.5	10.5	8
7.5	12	11	23	0.4	11.57	left	HL 12 GX B1	191 258/150	14	10	45	20	M14 x 1.5	6	23	56	72	128	22	8.8	6.5	10.5	8
11.8	12	12	24	0.7	11.33	right	HL 21 DX B1	191 240/050	16	14	52	25	M16 x 1.5	6	28	76	59	128	26	8.8	6.5	10.5	16
11.8	12	12	24	0.7	18.87	left	HL 21 GX B1	191 240/150	16	14	52	25	M16 x 1.5	6	28	63	59	128	26	8.8	6.5	10.5	16
23.6	15	14	29	1.6	27.44	right	HL 31 DX B1	192 229/050	18	20	72	36	M24 x 1.5	10	38	110	98	158.5	28	11	10.5	17	11
23.6	15	14	29	1.6	49.60	left	HL 31 GX B1	192 229/050	18	20	72	36	M24 x 1.5	10	38	90	98	158.5	28	11	10.5	17	11
36.5	15	17	32	2.8	46.15	right	HL 41 DX B1	192 230/050	20	22	88	42	M30 x 15.5	10	45	128	107	168.5	30	11	10.5	17	13
36.5	15	17	32	2.8	80.45	left	HL 41 GX B1	192 230/050	20	22	88	42	M30 x 15.5	10	45	108	107	168.5	30	11	10.5	17	13
