Lock washer for clamp type P11, P21

Print this sheet

The arm lock nut and lock washer are supplied with the clamps.

Lock washer for clamp type P11, P21 : Swing clamps with helical rotation - Quiri
Type Reference
øD





 ød





 L




mm mm mm
R 12 AQ 1407 23 14.5 3.7
R 21 AQ 1408 24.5 17 3.7

Compatible products

Double-acting swing clamp – Threaded – 250 bar – Supplied through taps on the head – threaded body P

Double-acting - planar rotation
Force at 250 bar: 4 to 24 kN

Double-acting swing clamp – 250 bar – Supplied through taps on the head – screw fastening PT

Double-acting - planar rotation
Max force at 250 bar: 4 to 24 kN

Double-acting swing clamp – 250 bar – Flanged base PF

Double-acting - planar rotation
Max force at 250 bar: 4 to 24 kN

Double-acting swing clamp – 250 bar – Supplied through taps on the base PS

Double-acting - planar rotation
Max force at 250 bar: 4 to 24 kN

Double-acting swing clamp – 250 bar – Supplied through counter-bores under the head PL

Double-acting - planar rotation
Max force at 250 bar: 4 to 24 kN

Double-acting swing clamp – 250 bar – Flanged cylindrical base PLF

Double-acting - planar rotation
Max force at 250 bar: 4 to 24 kN

Double-acting swing clamp – 250 bar – Flanged block PBF

Double-acting - planar rotation
Max force at 250 bar: 4 to 24 kN

Double-acting swing clamp – Flange cartridge – 250 bar PCB

Double-acting - planar rotation
Max force at 250 bar: 4 to 24 kN

Double-acting swing clamp – Screw cartridge – 250 bar PCV

Double-acting - planar rotation
Max force at 250 bar: 4 to 24 kN

See similar accessories

Clamping arm for swing clamp: P5 BP5

for swing clamp: H5

Short clamping arm – rod with 15° taper – For swing clamp size: 11 – 12 – 21 – 31 – 41 BC

for swing clamp size: 11 - 12 - 21 - 31 - 41
rod end with 15° taper

Short clamping arm – rod with 1:10 taper – For swing clamp size: 11 – 12 – 21 – 31 – 41 BCK

For swing clamp size: 11 - 12 - 21 - 31 - 41
rod end with 1:10 taper

Medium clamping arm – rod with 15° taper – For swing clamp size: 11 – 12 – 21 – 31 – 41 BM

For swing clamp size: 11 - 12 - 21 - 31 - 41
rod end with 15° taper
