Short clamping arm – rod with 1:10 taper – For swing clamp size: 11 – 12 – 21 – 31 – 41 BCK

For swing clamp size: 11 - 12 - 21 - 31 - 41
rod end with 1:10 taper

Short clamping arm – rod with 1:10 taper – For swing clamp size: 11 – 12 – 21 – 31 – 41 BCK : Swing clamps with helical rotation - Quiri

Definition

• with bevels dimensions e, p, s, t

Characteristics

• turns over 360°
• treated for corrosion protection
• maximum service pressure: 250 bar

Option

Special arms made on request.

Nota

The clamping force and maximum flow rate reduce as the arm length increases (see tables on the guide and H clamp charts).

Make sure the rod is held while fastening the screw.
see figure 1 on the guide

Print this sheet

Short clamping arm – rod with 1:10 taper – For swing clamp size: 11 – 12 – 21 – 31 – 41 BCK : Swing clamps with helical rotation - Quiri - 2

Taps	Bevels	Type	Reference
Taps	Bevels	Type	Reference	a	b	c	ød	e	f	h	k	l	øn	p	ør	s	t
				mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	°	°
WITHOUT	WITH	BCK 11	901-1-018	40	30	25	17.46	18	15	17	1	3	25	12	26	25	25
WITHOUT	WITH	BCK 12	901-1-020	49	34	32	19.46	20	17	19	1	5	33	14	28	25	25
WITHOUT	WITH	BCK 21	901-1-025	55	40	35	24.46	23	20	23	1	4	–	16.5	34	30	30
WITHOUT	WITH	BCK 31	901-1-036	72	55	44.5	35.46	30	27.5	30	1	5	47	20	45	30	30
WITHOUT	WITH	BCK 41	901-1-042	85	70	50	40.93	36	35	33	2	6	61	20	52	45	45
