RGP 9500 gas spring

• Diameter from 19 to 150 mm
• Stroke : from 7 to 125 mm
• Force : from 170 to 9500daN (9.5t)
• Very compact size
• Solid design (no welding)

Print this sheet
RGP 9500 gas spring : HIGH POWER RGP GAS SPRINGS - Quiri - 2
RGP 9500 gas spring : HIGH POWER RGP GAS SPRINGS - Quiri - 3
RGP 9500 gas spring : HIGH POWER RGP GAS SPRINGS - Quiri - 4
Type Force

daN

Stroke C

mm

Order code ISO Pressure

MPa (bar)

Force F1

N*

Force F2

N*

LR

mm

LC

mm

Weight

Kg

RGP 9500 19 443405/000 15

(150)

(!)

95 430 139 110 116 97 10.80
25 443406/000 X 143 320 128 103 11.40
32 443407/000 147 040 142 110 11.70
38 443408/000 X 149 300 154 116 12.10
50 443409/000 X 152 720 178 128 13.00
63 443410/000 X 155 080 204 141 14.00
75 443411/000 156 650 228 153 14.90
80 443412/000 X 157 140 238 158 15.30
100 443413/000 X 158 690 278 178 16.70
125 443414/000 X 160 980 328 203 18.40

* (N) = Kgf x 9.80665 | (Kgf)=N x 0.101972 | 1daN=1 x 101N | 1bar=1 x 10-1MPa

Example of order : RGP 9500 C50
DESP 97/23/EC Category II : these gas springs must be returned to the manufacturer for repairing.
Spare Kit : 896563/000.
Composition : Guide ring, seals, valve and lubricant.

RGP 9500 gas spring : HIGH POWER RGP GAS SPRINGS - Quiri - 5

(!) There is a blue sticker on the gas spring body when it is inflated with a special pressure (<15 MPa)

RGP 9500 gas spring : HIGH POWER RGP GAS SPRINGS - Quiri - 6
