RGP 750 N gas spring
| Type | Force | Stroke C | Reference | ISO | Pressure | Force F1 | Force F2 | LR | LC | Mass | 3D Model |
| daN | mm | MPa (bar) | N* | N* | mm | mm | Kg | ||||
| RGP | 750 | 10 | 443831/000-S | 15
(150) (!)
|
7 370 | 10 960 | 52 | 42 | 0.40 | 3D | |
| 13 | 443832/000-S | X | 11 100 | 58 | 45 | 0.42 | 3D | ||||
| 16 | 443834/000-S | 11 200 | 64 | 48 | 0.44 | 3D | |||||
| 19 | 443835/000-S | 11 260 | 70 | 51 | 0.46 | 3D | |||||
| 25 | 443836/000-S | X | 11 350 | 82 | 57 | 0.51 | 3D | ||||
| 32 | 443837/000-S | 11 470 | 96 | 64 | 0.55 | 3D | |||||
| 38 | 443838/000-S | X | 11 500 | 108 | 70 | 0.59 | 3D | ||||
| 50 | 443839/000-S | X | 11 540 | 132 | 82 | 0.67 | 3D | ||||
| 63 | 443840/000-S | X | 11 590 | 158 | 95 | 0.75 | 3D | ||||
| 75 | 443841/000-S | 11 600 | 182 | 107 | 0.83 | 3D | |||||
| 80 | 443842/000-S | X | 11 590 | 192 | 112 | 0;86 | 3D | ||||
| 100 | 443843/000-S | X | 11 590 | 232 | 132 | 0.99 | 3D | ||||
| 125 | 443844/000-S | X | 11 620 | 282 | 157 | 1.15 | 3D |
* (N) = Kgf x 9.80665 | (Kgf)=N x 0.101972 | 1daN=1 x 101N | 1bar=1 x 10-1MPa
Example of order: RGP 750 C50 N
Spare Kit : 896530/000.
Composition : Guide ring, seals, valve and lubricant.
(!) There is a blue sticker on the gas spring body when it is inflated with a special pressure (<15 MPa)
