RGP 4200 gas spring
| Type | Force
daN |
Stroke C
mm |
Order code | ISO | Pressure
MPa (bar) |
Force F1
N* |
Force F2
N* |
LR
mm |
LC
mm |
Weight
Kg |
| RGP | 4200 | 16 | 443364/000-S | 15
(150) (!) |
42 420 | 62 890 | 90 | 74 | 3.00 | |
| 19 | 443365/000-S | 63 870 | 96 | 77 | 3.10 | |||||
| 25 | 443366/000-S | X | 65 610 | 108 | 83 | 3.30 | ||||
| 32 | 443367/000-S | 66 790 | 122 | 90 | 3.50 | |||||
| 38 | 443368/000-S | X | 67 670 | 134 | 96 | 3.60 | ||||
| 50 | 443369/000-S | X | 68 770 | 158 | 108 | 4.00 | ||||
| 63 | 443370/000-S | X | 69 520 | 184 | 121 | 4.30 | ||||
| 75 | 443371/000-S | 70 020 | 208 | 133 | 4.60 | |||||
| 80 | 443372/000-S | X | 70 170 | 218 | 138 | 4.70 | ||||
| 100 | 443373/000-S | X | 70 700 | 258 | 158 | 5.30 | ||||
| 125 | 443374/000-S | X | 71 960 | 308 | 183 | 5.90 |
* (N) = Kgf x 9.80665 | (Kgf)=N x 0.101972 | 1daN=1 x 101N | 1bar=1 x 10-1MPa
Example of order : RGP 4200 C50
Spare Kit : 896534/000.
Composition : Guide ring, seals, valve and lubricant.
(!) There is a blue sticker on the gas spring body when it is inflated with a special pressure (<15 MPa)
