RGP 6600 gas spring

• Diameter from 19 to 150 mm
• Stroke : from 7 to 125 mm
• Force : from 170 to 9500daN (9.5t)
• Very compact size
• Solid design (no welding)

Print this sheet
RGP 6600 gas spring : HIGH POWER RGP GAS SPRINGS - Quiri - 2
RGP 6600 gas spring : HIGH POWER RGP GAS SPRINGS - Quiri - 3
RGP 6600 gas spring : HIGH POWER RGP GAS SPRINGS - Quiri - 4
RGP 6600 gas spring : HIGH POWER RGP GAS SPRINGS - Quiri - 5
Type Force

daN

Stroke C

mm

Order code ISO Pressure

MPa (bar)

Force F1

N*

Force F2

N*

LR

mm

LC

mm

Weight

Kg

RGP 6600 16 443384/000 15

(150)

(!)



66 270 95 130 100 84 5.70
19 443385/000 97 170 106 87 5.90
25 443386/000 X 100 230 118 93 6.20
32 443387/000 102 640 132 100 6.40
38 443388/000 X 104 230 144 106 6.70
50 443389/000 X 106 480 168 118 7.40
63 443390/000 X 108 040 194 131 7.80
75 ** 443391/000 109 020 218 143 8.40
80 ** 443392/000 X 109 360 228 148 8.60
100 ** 443393/000 X 110 490 268 168 9.50
125 ** 443394/000 X 114 320 318 193 10.90

* (N) = Kgf x 9.80665 | (Kgf)=N x 0.101972 | 1daN=1 x 101N | 1bar=1 x 10-1MPa
** DESP 97/23/EC Category II : these gas springs must be returned to the manufacturer for repairing.

Example of order: RGP 6600 C50
Spare Kit : 896561/000.
Composition : Guide ring, seals, valve and lubricant.

RGP 6600 gas spring : HIGH POWER RGP GAS SPRINGS - Quiri - 6

(!) There is a blue sticker on the gas spring body when it is inflated with a special pressure (<15 MPa)
