ISO GAS SPRINGS WITH CONNECTIONS
• Conform to standard dimensions ISO11901-1, CNOMO E.24.54.815.N
• Comply with European directive PED 97/23EC
• Force : from 250 to 10 000 daN (10t)
• Stroke : up to 300mm
• Designed for heavy duty
• Double sealing
• Oil lubricated guide ring
• Solid structure (no welding)
• Can be used in piping system
• Gas : Nitrogen
• Maximum inflating pressure : 150 bar
• Minimum inflating pressure : 25 bar
• Temperature limit : 0/+70°C
• Maximum piston rod speed : 1.6 m/s
BE CAREFULL : The RGR 250 is higher than the RG 250.
| Type | Force | Stroke C | Reference | Pressure | Force F1 | Force F2 | LR | LC |
| daN | mm | MPa (bar) | N* | N* | mm | mm | ||
| RGR | 250 | 10 | 442231/000 | 15
(150) (!)
|
2300 | 2900 | 85 | 75 |
| 16 | 442232/000 | 2930 | 97 | 81 | ||||
| 25 | 442233/000 | 115 | 90 | |||||
| 38 | 442236/000 | 141 | 103 | |||||
| 50 | 442234/000 | 2950 | 165 | 115 | ||||
| 80 | 442235/000 | 225 | 145 |
* (N) = Kgf x 9.80665 | (Kgf)=N x 0.101972 | 1daN=1 x 101N | 1bar=1 x 10-1MPa
(!) A blue mark is stuck to the spring when it is inflated to a special pressure. (<15 MPa)
