RG 7500
• Conform to standard dimensions ISO11901-1, CNOMO E.24.54.815.N
• Comply with European directive PED 97/23EC
• Force : from 250 to 10 000 daN (10t)
• Stroke : up to 300mm
• Designed for heavy duty
• Double sealing
• Oil lubricated guide ring
• Solid structure (no welding)
• Can be used in piping system
• Gas : Nitrogen
• Maximum inflating pressure : 150 bar
• Minimum inflating pressure : 25 bar
• Temperature limit : 0/+70°C
• Maximum piston rod speed : 1.6 m/s
For connection details of ISO standard gas springs, please see CONNECTIONS FOR ISO GAS SPRINGS
Also exists for high velocity.
For more information, please contact us
| Type | Force
daN |
Stroke C
mm |
Order code | ISO | Pressure
MPa (bar) |
Force F1
N * |
Force F2
N * |
LR
mm |
LC
mm |
Weight
Kg |
| RG | 7500 | 25 | 442631/000 | X | 15
(150) (!)
|
75 400 | 98 780 | 205 | 180 | 20.00 |
| 50 | 442632/000 | X | 105 220 | 255 | 205 | 22.00 | ||||
| 63 | 442702/000 | 105 690 | 282 | 219 | 23.00 | |||||
| 80 | 442633/000 | X | 108 620 | 315 | 235 | 24.00 | ||||
| 100 ** | 442694/000 | X | 109 940 | 355 | 255 | 26.00 | ||||
| 125 ** | 442695/000 | X | 111 090 | 405 | 280 | 28.00 | ||||
| 160 ** | 442696/000 | X | 112 160 | 475 | 315 | 31.00 | ||||
| 200 ** | 442697/000 | 112 950 | 555 | 355 | 35.00 | |||||
| 250 ** | 442698/000 | 113 640 | 655 | 405 | 39.00 | |||||
| 300 ** | 442699/000 | 114 090 | 755 | 455 | 44.00 |
* (N) = Kgf x 9.80665 | (Kgf)=N x 0.101972 | 1daN=1 x 101N | 1bar=1 x 10-1MPa
** Gas spring «Cat. II module D1» following PED 2014/68/EU : this gas spring must be returned to the manufacturer for repairing.
Example of order: RG 7500 C50
Spare Kits – Composition : Guide ring; seals, valve and lubricant.
– V1 (bronze ring and chrome piston rod) : 896495/000.
– V2 (Black steel ring and piston rod) : 896605/000.
(!) There is a blue sticker on the gas spring body when it is inflated with a special pressure (<15 MPa)
