Pressure screw with mushroom head for BDA

Print this sheet
Pressure screw with mushroom head for BDA : Hydraulic block cylinders BDA - Quiri
TYPE Units VA10.6 VA25.10 VA40.12 VA65.16 VA100.20 VA160.27
a M6 M10 M12 M16 M20 M27
b (mm) 10 12 12 20 25 30
c (mm) 20 22 22 30 35 47
R (mm) 20 35 45 60 60 100
CP (mm) 10 17 19 24 30 41
