Tapped feeding ports. Smooth holes with counterbores perpendicular to the rod.
Keyway on both sides, allowing the feed from the left or right side.
Key provided
Seals kits available on stock
Hydraulic block cylinders BDD
Other products
How to choose a Hydraulic block cylinders BDD Guide ?
Access Hydraulic block cylinders BDD 's products
Access selection
Back to Hydraulic block cylinders
Hydraulic block cylinders – BDD DG Type
Test pressure: 500 bars
Max working pressure: 350 bars
- Double rod sealing
- Solid body with burnished bore
- Solid piston rod, heat treated steel
- Strokes ± 0,3mm
- Warranty 2 years or 400 km (4 million cycles for a stroke of 50 mm)
- HELD IN STOCK
| TYPE | Units | BDD10 | BDD25 | BDD40 | BDD65 | BDD100 | BDD160 |
| Piston | (mm) | 16 | 25 | 32 | 40 | 50 | 63 |
| Rod | (mm) | 10 | 16 | 20 | 25 | 32 | 40 |
| Pushing force at 100 bars | (kN) | 2,0 | 4,9 | 8,0 | 12,5 | 19,6 | 31,1 |
| Pulling force at 100 bars | (kN) | 1,2 | 2,9 | 4,9 | 7,7 | 11,6 | 18,6 |
| a | (mm) | 60 | 65 | 75 | 85 | 100 | 125 |
| b | (mm) | 35 | 45 | 55 | 63 | 75 | 95 |
| c | (mm) | 6 | 7 | 10 | 10 | 10 | 14 |
| f | (mm) | 30 | 50 | 55 | 63 | 76 | 95 |
| g | (mm) | 6,5 | 8,5 | 10,5 | 10,5 | 13 | 17 |
| g1 x depth | (mm) | ø11 x 6,5 | ø14 x 9 | ø17 x 11 | ø17 x 11 | ø19 x 13 | ø25 x 17 |
| h | (mm) | 30 | 33 | 38 | 40 | 44 | 50 |
| j | (mm) | 8 | 10 | 12 | 12 | 16 | 20 |
| k | (mm) | 17,5 | 22,5 | 27,5 | 31,5 | 37,5 | 47,5 |
| n | (mm) | 16,5 | 18 | 22 | 24 | 27 | 26 |
| p | G1/4 | G1/4 | G1/4 | G1/4 | G1/4 | G1/2 | |
| z | (mm) | 2 | 2 | 3 | 3 | 5 | 5 |
| z’ | (mm) | 4 | 6 | 5 | 5 | 5 | 7 |
| Stroke | (mm) | 16 | 20 | 25 | 25 | 25 | 30 |
| Body length (L) | (mm) | 56 | 64 | 75 | 79 | 90 | 102 |
| Between feeding holes (m) | (mm) | 28,5 | 35 | 42 | 44 | 50 | 59 |
| Stroke | (mm) | 50 | 50 | 50 | 50 | 50 | 63 |
| Body length (L) | (mm) | 91 | 94 | 100 | 104 | 115 | 135 |
| Between feeding holes (m) | (mm) | 63,5 | 65 | 67 | 69 | 75 | 92 |
| Stroke | (mm) | – | 100 | 100 | 100 | 100 | 100 |
| Body length (L) | (mm) | – | 144 | 150 | 154 | 165 | 172 |
| Between feeding holes (m) | (mm) | – | 115 | 117 | 119 | 125 | 129 |
| 3D Model | 3D | 3D | 3D | 3D | 3D | 3D |
Rod ends
| TYPE | Units | BDD10 | BDD25 | BDD40 | BDD65 | BDD100 | BDD160 |
| ød | (mm) | 10 | 16 | 20 | 25 | 32 | 40 |
| B | (mm) | 4.5 | 5.8 | 7.5 | 8.5 | 9 | 12.2 |
| C | (mm) | M6 | M10 | M12 | M16 | M20 | M27 |
| øD | (mm) | 6.3 | 10.5 | 12.5 | 16.5 | 21 | 28 |
| øE | (mm) | 9.2 | 15.2 | 19 | 24 | 31 | 39 |
| K | (mm) | 8 | 13 | 17 | 22 | 27 | 36 |
| L | (mm) | 14 | 18 | 22 | 28 | 36 | 45 |
| M | (mm) | M8 x 1 | M14 x 1.5 | M16 x 1.5 | M20 x 1.5 | M27 x 2 | M33 x 2 |
| P | (mm) | 15 | 18 | 18 | 25 | 30 | 40 |
| Q | (mm) | 3 | 4 | 4 | 7 | 7 | 10 |
