T-Lock© self-locking anti-vibration support AVTL
Double-acting - supply through taps
Locking force: 5 to 20 kN
Absolute safety if pressure is lost!
This support uses the same locking principle as T-Lock® and maintains the exact support point position after hydraulic disconnection. It is completely insensitive to vibrations.
These supports use the principle of elasticity of materials.
Their operation comprises four phases:
1) Support piston release:
PC = 300 bar
2) Contact with workpiece:
Simultaneous pressure PA + PB = elastic deformation of the workpiece
3) Removal of pressure:
PA + PB = 0
The workpiece then pushes the rod due to elasticity.
The residual support force is provided by seal friction
4) Piston lock PC = 0:
The position is maintained without pressure.
• rear sensor rod to CNOMO standards
• custom double clamping may be made.
• pressure intensifier
• special models
|
Type
|
A
Rod extension |
B
Rod retraction |
C
Release |
| AVTL 5 | G 1/8″ | G 1/8″ | G 1/4″ |
| AVTL 10 | G 1/4″ | G 1/4″ | G 1/4″ |
| AVTL 20 | G 1/4″ | G 1/4″ | G 1/4″ |
* Active section with differential supply = Rod section.
| Contact force at 25 bar | Travel
+0.5 0 |
Active section
|
Rod øD | Rod ød | Locking force | Release
pressure +30 0 |
Type | Reference | a
|
b
|
c
|
e
|
f
|
g
ø |
h
|
k
|
m
|
n1
|
n2
|
p
|
r
|
s
|
t
|
u
|
| N | mm | cm2 | mm | mm | kN | bar | mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | |||
| 635 | 10 | 2.54 | 32 | 18 | 5
min |
300 | AVTL 5 | 761 042/000 | 120 | 74 | 65 | 60 | 48 | 9 | 26 | 30 | M6 | 10 | 10 | 10.5 | 15 | 14.5 | 8 | 16 |
| 950 | 10 | 3.80 | 40 | 22 | 10
min |
300 | AVTL 10 | 761 023/000 | 142 | 90 | 78 | 72 | 56 | 11 | 30 | 35 | M8 | 12.5 | 11 | 13 | 19 | 18 | 8 | 20 |
| 1540 | 10 | 6.16 | 55 | 28 | 20
min |
300 | AVTL 20 | 761 043/000 | 160 | 108 | 96 | 87 | 60 | 13 | 32 | 37 | M10 | 14 | 12 | 16 | 21 | 21 | 8 | 26 |
