T-Lock© self-locking linear clamp TL

Double-acting - Supply through taps
Locking force: 15 to 50 kN

Definition

Absolute safety if pressure is lost!

This locking system uses the absence of pressure and makes it possible to maintain fully controlled clamping force when the clamp is disconnected from its source. In addition it is completely insensitive to vibrations.

In all applications involving palletising, transfer, quick changing of press tools, mould closing and test benches, these clamps provide safe operation.

Characteristics

• supply through gas taps
• locked by the absence of pressure
• piston release pressure: 300 or 500 bar

Options

• sensing rod to CNOMO standards
• double clamping arm available on request
• pressure intensifier on request
• special models on request

Print this sheet

T-Lock© self-locking linear clamp TL : Positive locking cylinders - Quiri - 2


Type	A Rod extension	B Rod retraction	C Release
TL 15	G 1/8″	G 1/8″	G 1/4″
TL 30	G 1/4″ *	G 1/4″ *	G 1/4″
TL 50	G 1/4″ *	G 1/4″ *	G 1/4″

* G 3/8″ on request

** The length “a” of the clamp depends on the release pressure and the locking force required.
Special models can be made upon request.

Thrust force	Tractive force	Travel +0.5 0	Active section		Rod øD	Rod ød	Locking force	Release pressure +30 0	Type
Thrust force	Tractive force	Travel +0.5 0	Active section		Rod øD	Rod ød	Locking force	Release pressure +30 0	Type	a	b	c	e	f	g ø	h	k	m ø	n1	n2	p	r	s	t	u	v
kN	kN	mm	cm²		mm	mm	kN	bar		mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm		mm
15 at 186 bar	15 at 230 bar	10	P	8.04	32	14	15 min	500	TL 15/5	120	74	65	60	48	9	26	30	30	10	10	10.5	15	14.5	16	M12 x 1.5	30	3D
15 at 186 bar	15 at 230 bar	10	T	6.50	32	14	15 min	300	TL 15/3	193	74	65	60	48	9	26	30	30	10	10	10.5	15	14.5	16	M12 x 1.5	30	3D
30 at 238 bar	30 at 299 bar	10	P	12.56	40	18	30 min	500	TL 30/5	142	90	78	72	56	11	30	35	34	12.5	11	13	19	18	18	M16 x 1.5	35	3D
30 at 238 bar	30 at 299 bar	10	T	10.02	40	18	30 min	300	TL 30/3	215	90	78	72	56	11	30	35	34	12.5	11	13	19	18	18	M16 x 1.5	35	3D
50 at 210 bar	50 at 250 bar	10	P	23.75	55	22	50 min	500	TL 50/5	160	108	96	87	60	13	32	37	42	14	12	16	21	21	28	M20 x 1.5	44	3D
50 at 210 bar	50 at 250 bar	10	T	19.95	55	22	50 min	300	TL 50/3	238	108	96	87	60	13	32	37	42	14	12	16	21	21	28	M20 x 1.5	44	3D

T-Lock© self-locking linear clamp TL

Definition

Characteristics

Options

View similar products

T-Lock© and R-Lock© – Flanged TLF et RLF
