500V series plunger cylinders

P - 500V

Features
On demand

Features

High-performance cylinders for all applications, particularly suited to very hard operating conditions with high loads in small spaces (steelworks, public works, presses, etc.).
• Chevron seals on piston and rod for standard version
• Pressure in intermittent service : 500 bar
• Intensive operating : 400 bar
• Maximum speed : 0,5 m/s with standard seals, up to 2 m/s with special seals
• Maximum temperature : 100°C with standard seals, up to 200°C with Viton seals

On demand

• Other threads k
• Metric thread on Ø e
• Choice of port connection – head (front) – Bottom (rear)
The other port is blocked by a steel plug and gasket.
• The rear endeye on VO-type cylinders can be supplied in the following versions :
– Ø S smooth
– with ball joint, grease nipple
– or with bronze bushing

Print this sheet

Designation

500V series plunger cylinders : 500 bar hydraulic cylinders - Quiri - 2

Dimensions

500V series plunger cylinders : 500 bar hydraulic cylinders - Quiri - 3

Bore Ø A	25	32	40	50	63	80	100	125	140	160	200
Rod Ø D	18	22	28	40	50	63	80	100	110	125	160
a	106	123	155	158	200	230	255	315	335	375	470
b	8	8	10	10	15	15	15	20	20	25	30
c	35	42	52	70	83	106	132	170	190	212	270
d	50	60	70	85	105	135	165	210	240	250	330
e	42	52	58	75	95	116	146	186	208	235	290
f	11	12	16	18	20	22	25	30	30	30	40
g	42.5	47.5	56.5	67.5	82	98	115	135	145	160	195
h	G 1/4	G 1/4	G 3/8	G 3/8	G 1/2	G 1/2	G 3/4	G 3/4	G 3/4	G 1	G 1
j	21	21	24	24	31	31	36	36	36	42	42
k	M 12 x 1	M 14 x 1	M 18 x 1.5	M 24 x 1.5	M 27 x 1.5	M 35 x 1.5	M 45 x 1.5	M 55 x 1.5	M 64 x 1.5	M 72 x 1.5	M 90 x 2
m	12	14	18	24	27	35	45	55	64	72	90
p	17.5	22.5	32.5	42.5	60	75	90	100	110	125	155
r mini/maxi	15/20	20/25	25/30	35/40	45/50	50/60	60/70	80/90	80/90	90/100	110/120
s	26	30	35	47	62	75	90	120	130	150	180
t	18	22	28	35	45	55	70	90	100	110	140
u	50	50	50	50	50	50	55	70	70	70	80
y	124	146	175	193	245	280	325	405	435	485	610
Stroke mini	20	20	30	30	50	50	50	50	100	100	100
Thread on Ø e	M 42 x 1.5	M 52 x 1.5	M 58 x 2	M 75 x 2	M 94 x 2	M 112 x 3	M 140 x 2	M 186 x 3	M 206 x 2	M 200 x 3	M 250 x 3

500V series plunger cylinders : 500 bar hydraulic cylinders - Quiri - 4

References

Bore / Rod		25/18	32/22	40/28	50/40	63/50	80/63	100/80	125/100	140/110	160/125	200/160
VN bottom	F Rod	121020	121026	121032	121038	122020	122026	123020	124010	125010	125016	126016
VN bottom	T Rod	121021	121027	121033	121039	122021	122027	123021	124011	125011	125017	126017
VO bottom	F Rod	121022	121028	121034	121040	122022	122028	123022	124012	125012	125018	126018
VO bottom	T Rod	121023	121029	121035	121041	122023	122029	123023	124013	125013	125019	126019

Technical specifications

Cylinder force in 10⁴ N at 500 bar

Bore	25	32	40	50	63	80	100	125	140	160	200
Section in cm²	2.36	4.24	6.4	7.07	11.53	19.09	28.27	44.17	58.9	78.34	113.1
Pushing force in 10⁴N	1.16	2.08	3.14	3.46	5.65	9.36	13.86	21.65	28.87	38.4	55.45

Cylinder weight in Kg

Bore		25	32	40	50	63	80	100	125	140	160	200
VN TYPE CYLINDER	P	1.37	2.6	3.6	6.5	12	21	40	81	106	142	275
VO TYPE CYLINDER	P	1.47	2.8	4	7.3	13	25	47	95	125	166	330
Per stroke mm	Z	0.006	0.007	0.011	0.024	0.032	0.054	0.083	0.14	0.17	0.21	0.35
