SE - 500V
High-performance cylinders suitable for all applications, particularly in very hard operating conditions with high loads in small spaces (steelworks, public works, presses, etc.).
• Chevron seals on piston and rod for standard version
• Pressure in intermittent service : 500 bar
• Intensive operating : 400 bar
• Maximum speed : 0,5 m/s with standard seals, up to 2 m/s with special seals
• Maximum temperature : 100°C with standard seals, up to 200°C with viton seals
• Other threads k
• Metric thread on Ø e
• Damping (damping stroke to be specified)
• Double-rod cylinder
• The rear endeye on VO-type cylinders can be supplied in the following versions :
– Ø S smoth
– with ball joint, snap ring and grease nipple
– or with bronze bushing
Bore Ø A | 25 | 32 | 40 | 50 | 63 | 80 | 100 | 125 | 140 | 160 | 200 |
Rod Ø D | 18 | 22 | 28 | 40 | 50 | 63 | 80 | 100 | 110 | 125 | 160 |
a | 128 | 148 | 175 | 190 | 235 | 275 | 315 | 385 | 405 | 440 | 540 |
b | 8 | 8 | 10 | 10 | 15 | 15 | 15 | 20 | 20 | 25 | 30 |
c | 35 | 42 | 52 | 70 | 83 | 108 | 132 | 170 | 190 | 212 | 270 |
d | 50 | 60 | 70 | 85 | 105 | 135 | 165 | 210 | 240 | 260 | 330 |
e | 42 | 52 | 58 | 75 | 95 | 116 | 146 | 186 | 208 | 235 | 290 |
f | 11 | 12 | 16 | 18 | 20 | 22 | 25 | 35 | 35 | 35 | 40 |
g | 45 | 47.5 | 56.5 | 67.5 | 82 | 98 | 115 | 135 | 143 | 160 | 195 |
h | G 1/4 | G 1/4 | G 3/8 | G 3/8 | G 1/2 | G 1/2 | G 3/4 | G 3/4 | G 3/4 | G 1 | G 1 |
i | 21 | 21 | 24 | 24 | 31 | 31 | 36 | 36 | 36 | 42 | 42 |
k | M 12 x 1 | M 14 x 1 | M 18 x 1.5 | M 24 x 1.5 | M 27 x 1.5 | M 35 x 1.5 | M 45 x 1.5 | M 55 x 1.5 | M 64 x 1.5 | M 72 x 1.5 | M 90 x 2 |
m | 12 | 14 | 18 | 24 | 27 | 35 | 45 | 55 | 64 | 72 | 90 |
p | 17.5 | 22.5 | 32.5 | 42.5 | 60 | 75 | 90 | 100 | 110 | 125 | 155 |
r mini/maxi | 15/20 | 20/25 | 25/30 | 35/40 | 45/50 | 50/60 | 60/70 | 80/90 | 80/90 | 90/100 | 110/120 |
s | 26 | 30 | 35 | 47 | 62 | 75 | 90 | 120 | 130 | 150 | 180 |
t | 18 | 22 | 28 | 35 | 45 | 55 | 70 | 90 | 100 | 110 | 140 |
u | 50 | 50 | 50 | 50 | 50 | 50 | 55 | 70 | 70 | 70 | 80 |
y | 147 | 170 | 203 | 225 | 280 | 325 | 385 | 475 | 505 | 550 | 680 |
Stroke mini | 20 | 20 | 30 | 30 | 50 | 50 | 50 | 50 | 100 | 100 | 100 |
Thread on Ø e | M 42 x 1.5 | M 52 x 1.5 | M 58 x 2 | M 75 x 2 | M 94 x 2 | M 112 x 3 | M 140 x 2 | M 186 x 3 | M 206 x 2 | M 255 x 3 | M 250 x 3 |
Bore / Rod | 25/18 | 32/22 | 40/28 | 50/40 | 63/50 | 80/63 | 100/80 | 125/100 | 140/110 | 160/125 | 200/160 | |
VN bottom | Rod F | 111036 | 111031 | 111041 | 112022 | 112033 | 113035 | 114020 | 115010 | 116042 | 116048 | 117044 |
Rod T | 111037 | 111032 | 111042 | 112023 | 112034 | 113036 | 114021 | 115011 | 116043 | 116049 | 117045 | |
VO bottom | Rod F | 111038 | 111033 | 111043 | 112024 | 112035 | 113037 | 114022 | 115012 | 116044 | 116050 | 117046 |
Rod T | 111039 | 111034 | 111044 | 112025 | 112036 | 113038 | 114023 | 115013 | 116045 | 116051 | 117047 |
Single-acting “pull” cylinders, sealed on the return side, are obtained from double-acting cylinders with pull rod; the supply port on the push side, not used in this case, is fitted with an air filter.
Bore | 25 | 32 | 40 | 50 | 63 | 80 | 100 | 125 | 140 | 160 | 200 |
Section in cm2 | 4.9 | 8.04 | 12.56 | 19.63 | 31.17 | 50.26 | 78.54 | 122.71 | 153.93 | 201.06 | 314.16 |
Pushing force in 104N | 2.40 | 3.94 | 6.16 | 9.62 | 15.28 | 24.64 | 38.50 | 60.15 | 75.46 | 98.56 | 154 |
Bore | 25 | 32 | 40 | 50 | 63 | 80 | 100 | 125 | 140 | 160 | 200 | |
VN TYPE CYLINDER | P | 1.37 | 2.6 | 3.6 | 6.5 | 12 | 21 | 40 | 81 | 106 | 142 | 275 |
VO TYPE CYLINDER | P | 1.47 | 2.8 | 4 | 7.3 | 13 | 25 | 47 | 95 | 125 | 166 | 330 |
Per stroke mm | Z | 0.006 | 0.007 | 0.011 | 0.024 | 0.032 | 0.054 | 0.083 | 0.14 | 0.17 | 0.21 | 0.35 |
Determining the weight of a cylinder : Weight in kg = P + (Z x stroke in mm)
Numerical example :
Bore Ø 125 VN Type : P=81
Per mm of stroke : Z=0,14
Stroke in mm : 800
Weight =80+(0,14*800) = 193 kg
