For single and double acting cylinders
Hydraulic pressure proportional to air pressure
Working cycle : advance / hold / return
External adjustable pressure relief valve, set at 700 bar
Oil capacity 4000 and 12000 cm³ (delivered with oil)
Air inlet pressure: 7 bar
Oil flow: from 2400 to 25 cm³/min
Air consumption: 1800 l/min (without load) at 6 bar air pressure
Other relief valve setting : on request
Maxi. oil pressure
at 7 bar air bar |
Oil flow
(no load) cm3 |
Oil flow
(at 700 bar) cm3 |
Usable oil
capacity cm3 |
Reference | To use with
cylinder … |
Dimensions (mm) | Weight
Kg |
|||||||||
a | b | c | c’ | d | e | f | g | h | i | |||||||
700 | 2400 | 25 | 4000 | PHP 743 | single acting | 340 | 130 | 200 | 200 | 35 | 419 | 255 | 242 | 225 | 15 | 26 |
700 | 2400 | 25 | 4000 | PHP 744 | double acting | 340 | 130 | 200 | 200 | 35 | 419 | 255 | 242 | 225 | 15 | 26 |
700 | 2400 | 25 | 13500 | PHP 7123 | single acting | 430 | 130 | 200 | 324 | 35 | 509 | 395 | 332 | 365 | 15 | 38 |
700 | 2400 | 25 | 13500 | PHP 7124 | double acting | 430 | 130 | 200 | 324 | 35 | 509 | 395 | 332 | 365 | 15 | 38 |
