Double acting hand pumps, 2 speeds – 700 bar – PMD

For double acting cylinders

Double acting hand pumps, 2 speeds – 700 bar – PMD : Hydraulic hand pumps 700 bar - Quiri

Features
Options

Features

• 2 automatic speeds
• External adjustable pressure relief valve, set at 700 bar
• Delivered with oil

Options

Other relief valve setting : on request

Print this sheet

Double acting hand pumps, 2 speeds – 700 bar – PMD : Hydraulic hand pumps 700 bar - Quiri - 2

PMD 722

Double acting hand pumps, 2 speeds – 700 bar – PMD : Hydraulic hand pumps 700 bar - Quiri - 3

PMD 725

Double acting hand pumps, 2 speeds – 700 bar – PMD : Hydraulic hand pumps 700 bar - Quiri - 4

For cylinder	Pressure	Oil flow	Max pressure	Oil flow	Oil capacity		Max handle effort	Reference	Dimensions (mm)											Weight
	Pressure	Oil flow	Max pressure	Oil flow	Oil capacity				a	b	c	d	d’	e	f	g	h	i	i’
	bar	cm3/pump stroke	bar	cm3/pump stroke	Total	Usable
	BP		HP		cm3	cm3	daN													kg
double acting	27	39.5	700	2.8	2500	2200	48	PMD 722	633	222	195	122	122	150	159	502	596	38	80	14
double acting	27	39.5	700	2.8	5000	4450	48	PMD 725	633	210	195	90	126	146	150	502	492	35	80	21

PMD 727

Double acting hand pumps, 2 speeds – 700 bar – PMD : Hydraulic hand pumps 700 bar - Quiri - 5

For cylinder	Pressure	Oil flow	Max pressure	Oil flow	Oil capacity		Max handle effort	Reference	Dimensions (mm)										Weight
	Pressure	Oil flow	Max pressure	Oil flow	Oil capacity				a	b	c	d	e	f	g	h	i	j
	bar	cm3/pump stroke	bar	cm3/pump stroke	Total	Usable
	BP		HP		cm3	cm3	daN												kg
double acting	27.5	113	700	4	8000	7000	65	PMD 727	635	315	261	310	170	192	310	635	171	25	25

Product accessories

ø 100 pressure gauge adaptor – 700 bar – AM 135

ø 100 pressure gauge – 700 bar

Standard Thermoplastic hoses (internal Ø 6mm) – 700 bar

Internal 6mm
