Hollow piston single acting cylinders, spring return – 500 bar – SLC

Light alloy

Features
Options

Features

• Single acting, spring return
• Maximum pressure 600 bar (stroke to be limited at 80% of the whole stroke)
• Corrosion resistant light alloy body
• Chrome plated piston rod for cylinder 13 T
• Corrosion resistant light alloy piston rod for cylinders 35, 55, 80 T
• Wiper seals
• Delivered in standard without coupler

Options

A+B : Body collar thread with rubber protection *
F : 4 base threaded mounting holes

Print this sheet

Hollow piston single acting cylinders, spring return – 500 bar – SLC : Lifting light alloy cylinders 500 bar - Quiri - 2

Cylinder category	Working force 500 bar	Maximum force 600 bar	Stroke	Effective area	Oil volume	Reference	Dimensions (mm)								Options			Weight
Cylinder category	Working force 500 bar	Maximum force 600 bar	Stroke	Effective area	Oil volume	Reference	Dimensions (mm)								Option A *		Option F	Weight
Tons	kN	kN	mm	cm2	cm3		a	b	c	d	h	j	a1	q	e	f	M x p on Øg	kg
13	129,6	155,6	60	25,92	160	SLC 13/60	70	225	222	100,5	28	55	40	27	M100 x 2	40	M8 x 20 on Ø 65	6,8
35	333,8	400,5	60	66,76	400	SLC 35/60	110	240	236	145,5	43	85	60	44	145 x 3 **	45	M10 x 22 on Ø 90	10,8
35	333,8	400,5	125	66,76	835	SLC 35/125	110	370	364	145,5	43	85	60	48	145 x 3 **	45	M10 x 22 on Ø 90	15,8
55	548,8	658,5	55	109,76	604	SLC 55/55	140	270	266	190,5	55	110	75	55	190 x 4 **	50	M10 x 22 on Ø 120	23,2
80	816,8	980,1	50	163,36	817	SLC 80/50	170	290	285	230,5	55	140	90	70	225 x 5 **	50	M12 x 25 on Ø 150	34
