Single acting cylinders, load return – 500 bar – SLS

Light alloy

Features
Options

Features

• Single acting, load return
• Maximum pressure : 600 bar (stroke to be limited at 80% of the whole stroke)
• Corrosion resistant light alloy body (except 6T model in steel)
• Chrome plated piston rod
• Wiper seal
• Delivered in standard without coupler

Options

F : 4 base threaded mounting holes
T : Threading of the hole ø16mm on SLS 6/20

Print this sheet

Single acting cylinders, load return – 500 bar – SLS : Lifting light alloy cylinders 500 bar - Quiri - 2

Single acting cylinders, load return – 500 bar – SLS : Lifting light alloy cylinders 500 bar - Quiri - 3

Cylinders category	Working force 500 bar	Maxi force 600 bar	Stroke	Effective area	Oil volume	Reference	Dimensions (mm)						Option F	Weight
Cylinders category	Working force 500 bar	Maxi force 600 bar	Stroke	Effective area	Oil volume	Reference	a	b	c	d	h	j	M x p on Øg	Weight
Tons	kN	kN	mm	cm2	cm3		a	b	c	d	h	j	M x p on Øg	kg
6	62,8	75,4	20	12,56	25	SLS 6/20	40	62	61		22	32		0,7
10	98,2	117,8	30	19,63	59	SLS 10/30	50	120	117	68,5	21	40	M6 x12 on Ø50	1,8
20	192,4	230,8	30	38,48	115	SLS 20/30	70	105	104	100,5	21	60	M8 x 12 on Ø80	3,3
45	475	569,9	30	95,03	285	SLS 45/30	110	145	142	145,5	25	95	M10 x 15 on Ø120	11
75	769,3	923,2	30	153,93	462	SLS 75/30	140	170	167	190,5	25	125	M10 x15 on Ø160	15
110	1134,4	1361,2	30	227	681	SLS 110/30	170	190	187	230,5	30	150	M12 x 20 on Ø190	24,5
