Single acting, load return – 700 bar – SEG

Steel

Features

• Single acting, load return
• Fitted with removable grooved saddle
• Salt bath nitriding piston rod
• Fitted in standard with HF 738 coupler
• Cylinder SEG 506 with carrying handles
• Cylinder SEG 936 with transport eye hooks

Options

F 2 base threaded mounting holes

Print this sheet
Single acting, load return – 700 bar – SEG : Lifting steel cylinders 700 bar - Quiri - 2
Cylinder

category

 Maxi. force

700 bar



 Stroke Effective

area

 Oil volume Reference Dimensions (mm) Option F Weight
a b b’ c d h i j k m n o M x p on  g
Tons kN mm cm2 cm3 kg
11 111.3 38 15.9 60 SEG113* 45 109 125 107 60 23 70 39 27 9 2 18 M6 x 8 on ø 40 2.2
11 111.3 40 15.9 63.3 SEG114 45 89 105.5 86 69 21 65 38 27 9 2 19.5 M6 x 8 on ø 40 2.5
22 218.2 40 31.17 124.7 SEG224 63 96 116.5 92.5 89 21 65 53 39 12 2 24 M6 x 8 on ø 59 4.2
23 232.2 50 33.18 166 SEG235* 65 124 145 122 85 23 70 54 39 12 2 23 M6 x 8 on ø 59 5
31 309.3 60 44.18 265 SEG316 75 120 140.6 117 103 21 65 60 45 12 2 23.6 M8 x 8 on ø 65 6.7
50 496.2 60 70.88 425 SEG506 95 127 152 124 127 22 65 80 60 13 2 28 M8 x 10 on ø 90 10.7
54 549.5 50 78.54 393 SEG545* 100 138 162 135 130 23 70 80 56 12 3 27 M8 x 10 on ø 90 12.9
93 928.7 50 132.73 664 SEG935* 130 132 164 127 160 23 70 105 73.5 12 3 35 20
93 929.1 60 132.73 796.4 SEG936 130 141 170.5 137.5 168 21 65 110 94 16 2 33 M10 x 12 on ø 125 21.1

* Cylinder at end of life, last parts in stock

Product accessories

Find our guide about couplers on this page: Couplers fitted on single acting QUIRI 700 cylinders

TPP – Flat saddles – 700 bar

Standard saddles delivered on QUIRI 700 cylinders. Protect piston rod end.

TRP – Tilt saddles – 700 bar

Correct the effects of a non centered load.
