Single acting cylinders, spring return (23 to 93 T) – 700 bar – SER

Steel

Features

Features

• Single acting, spring return
• Collar thread with rubber protection
• Threaded piston end with removable grooved saddle (23 and 31T models)
• Threaded piston end with flat grooved saddle (54 and 93T model)
• 2 base threaded mounting holes
• Salt bath nitriding piston rod
• Fitted in standard with HF 738 coupler
• Cylinders SER 5415, 7515, 935 with carrying handles
• Cylinders SER 9315 with 2 transport eye hooks

Print this sheet

Single acting cylinders, spring return (23 to 93 T) – 700 bar – SER : Lifting steel cylinders 700 bar - Quiri - 2

Cylinder category	Maximum Force 700 bar	Stroke	Effective area	Oil volume	Reference	Dimensions (mm)																Weight
						a	b	b’	c	d	e	f	M x p sur g	h	i	j	k	l	m	n	o

Tons	kN	mm	cm2	cm3																		kg

23	232,2	25	33,18	83	SER232	65	140	162	128	85	35/16-12UNS	49	1/2-13UNC x 18 sur ø59	20	70	54	55	11/2-16UN	25	10	32	5,8
		50		166	SER235		165	187	153													6,8
		100		332	SER2310		216	238	204													8,95
		150		498	SER2315		267	289	255													11,1
		200		664	SER2320		324	346	312													13
		250		830	SER2325		375	397	363													15,5
31	309,1	50	44,18	220	SER315	75	194	216	184	100	35/16-12UNS	51		37	70	57,15	55	11/2-16UN	25	10	32	11
		150		660	SER3115		294	316	284													16,7
		200		880	SER3120		344	366	334													19,5
54	549,5	50	78,54	392	SER545	100	169	193	163	130	5-12UN	45	1/2-13UNC x 18 sur ø95	25	70	80	56		12	3	27	15,9
		100		784	SER5410		219	243	213													18,4
		150		1176	SER5415		269	293	263													25,3
93	928,7	50	132,73	664	SER935	130	190	222	185	175	67/8-12UN	50		47	70	105	73,5		12	3	35	32,3
		150		1992	SER9315		290	322	285													49,3
