Hollow piston double acting cylinders, hydraulic return – 700 bar – CDE

Steel

Features

Features

Double acting, hydraulic return
Threaded piston end with hollow saddle TLC
2 base threaded mounting holes
Salt bath nitriding piston rod
Fitted in standard with couplers HF 738 and safety valve on the retract side
Cylinders CDE2915 and CDE5815 with carrying handles
Cylinder CDE9015 with 2 transport eye hooks

Print this sheet

Hollow piston double acting cylinders, hydraulic return – 700 bar – CDE : Lifting steel cylinders 700 bar - Quiri - 2

Cylinder category	Maximum force 700 bar * kN		Stroke	Effective area	Oil volume	Reference	Dimensions (mm)												Weight
							a	b	d	M x p on ø g	h/h’	i/i’	j	k	l	m	n	q
Tons			mm	cm2	cm3														kg
29	P	297,3	150	42,51	638	CDE 2915	85,72	296	110	3/8 – 16UNC x 15 on ø 92,1	20/249	70/113	62	61	M46x1,5	22	10	33	19,2
	R	192,5		27,52	413
58	P	590	150	84,34	1265	CDE 5815	125	302	155	1/2 – 13UNC x 18 on ø 130,2	20/254	70/113	94	93	M72x1,5	25	12	53,5	32,7
	R	372,6		53,32	800
90	P	899,1	150	133	1995	CDE 9015	165,1	310	200		38/260	70/113	128	127	M104x1,5	30	12	79	53
	R	575,4		85,40	1281
