Single acting cylinders, spring return (5 to 16 T) – 700 bar – SER

Steel

• Single acting, spring return
• Collar thread with rubber protection
• Threaded piston end with removable grooved saddle
• 2 base threaded mounting holes
• Salt bath nitriding piston rod
• Fitted in standard with HF 738 coupler

Print this sheet
Single acting cylinders, spring return (5 to 16 T) – 700 bar – SER : Lifting steel cylinders 700 bar - Quiri - 2
Cylinder

category

Maximum force

700 bar

Stroke Effective

area

Oil volume Reference Dimensions (mm) Weight
a b b’ c d e f M x p

 sur g

h i j k l m n o
Tonnes kN mm cm2 cm3 kg
5 49,5 25 7,06 18 SER52 30 110 125 102 40 11/2-16UN 29 1/4-20UNC

x  12

sur ø25

20 70 26 26 3/4-16 UNF 16 6 21 1
75 54 SER57 160 175 152 1,45
125 90 SER512 212 227 204 1,92
175 126 SER517 273 288 271 2,48
225 162 SER522 324 339 322 2,94
11 111,3 25 15,9 40 SER112 45 119 138 111 60 21/4-14UNS 27 5/16-18UNC

x 15

sur ø40

20 70 39 40 1-8 UNC 17 6 25 2,4
50 80 SER115 144 163 136 2,9
100 160 SER1110 194 213 186 3,9
150 240 SER1115 244 263 236 4,9
200 320 SER1120 298 317 290 6
250 400 SER1125 348 367 340 7
16 166,3 25 23,75 60 SER162 55 124 159 112 70 23/4-16UN 30 3/8-16UNC

x 15

sur ø48

20 70 46 45 1-8 UNC 17 10 25 3,45
50 120 SER165 149 164 137 4,15
100 240 SER1610 200 215 188 5,55
150 360 SER1615 252 267 240 7
200 480 SER1620 309 324 297 8,6
250 600 SER1625 362 377 350 10,1

Product accessories

Find our guide about couplers on this page: Couplers fitted on single acting QUIRI 700 cylinders
