Lock nut cylinders, load return – 700 bar – SGS

Steel

Features
Options

Features

• Single acting, load return
• Threaded piston end with flat grooved saddle
• Salt bath nitriding piston rod and lock nut
• Fitted in standard with HF 738 coupler
• Cylinder SGS5415 with carrying handles
• Cylinder SGS9315 and SSL with 2 transport eye hooks

Options

F : 2 base threaded mounting holes

Print this sheet

Lock nut cylinders, load return – 700 bar – SGS : Lifting steel cylinders 700 bar - Quiri - 2

Cylinder category	Maximum force 700 bar	Stroke	Effective area	Oil volume	Reference	Dimensions (mm)														Option F	Weight
						a	b	b’	c	d	e	f	h	i	j *	k	m	n	o	M x p on g
Tons	kN	mm	cm2	cm3																	kg
31	309,1	150	44,18	660	SGS3115	75	274	295	272	100	100	25	23	70	21/4×5	39	12	2	23	M8x10 sur ø 65	14,5
54	549,5	150	78,54	1176	SGS5415	100	293	317	290	130	129	31	23	70	80×5	56	12	3	27	M8x10 sur ø 90	27,2
93	928,7	150	132,73	1992	SGS9315	130	325	357	322	175	169	36	47	70	105×5	73,5	12	3	35	M10x15 sur ø 110	56,4
200	1983,7	150	283,52	4252	SSL20015	190	374	421	367	242	241	57	62	70	160×5	113	13	5	52		125
300	3034,6	150	433,73	6506	SSL30015	235	435	501	428	302	302	69	78	70	180×5	130	25	5	71		222
		250		10843	SSL30025		545	611	538												269
400	4005,9	150	572,5	8590	SSL40015	270	450	535	443	349	348	74	88	70	220×5	160	25	5	90		315
		240		13740	SSL40024		550	635	543												375
500	5111,8	150	730,62	10960	SSL50015	305	475	575	468	392	392	80	91	70	260×5	180	25	5	105		427
		190		13881	SSL50019		525	625	518												458
