RGT 350 gas spring
• Diameter from 32 to 150 mm
• Stroke from 10 to 125 mm
• Force : from 350 to 9500 daN (9.5t)
• Designed especially for car makers
• Solid design (no welding)
• Design and features similar to RGP but can be used with standard G 1/8’’ piping system (except RGT 350)
• Long bottom threads recommended for fixtures with screws in the upper die
• Conforms to Toyota standard : SMS DNH 3203 N
| Type | Force | Stroke C | Reference | Pressure | Force F1 | Force F2 | LR | LC | Mass | 3D Model |
| daN | mm | MPa (bar) | N* | N* | mm | mm | Kg | |||
| RGT | 350 | 10 | 443541/000-S | 18
(180) (!)
|
3 620 | 5 080 | 66 | 50 | 0,220 | 3D |
| 13 | 443542/000-S | 5 110 | 66 | 53 | 0,250 | 3D | ||||
| 16 | 443544/000-S | 5 120 | 72 | 56 | 0,258 | 3D | ||||
| 19 | 443545/000-S | 5 320 | 78 | 59 | 0,268 | 3D | ||||
| 25 | 443546/000-S | 5 280 | 90 | 65 | 0,290 | 3D | ||||
| 32 | 443547/000-S | 5 220 | 104 | 72 | 0,314 | 3D | ||||
| 38 | 443248/000-S | 5 320 | 116 | 78 | 0,338 | 3D | ||||
| 50 | 443549/000-S | 5 280 | 140 | 90 | 0,372 | 3D | ||||
| 63 | 443550/000-S | 5 300 | 166 | 103 | 0,412 | 3D | ||||
| 75 | 443551/000-S | 5 280 | 190 | 115 | 0,448 | 3D | ||||
| 80 | 443552/000-S | 5 290 | 200 | 120 | 0,464 | 3D | ||||
| 100 | 443553/000-S | 5 320 | 240 | 140 | 0,565 | 3D | ||||
| 125 | 443554/000-S | 5 310 | 290 | 165 | 0,608 | 3D |
* (N) = Kgf x 9.80665 | (Kgf)=N x 0.101972 | 1daN=1 x 101N | 1bar=1 x 10-1MPa
Example of order : RGT 350 C50
Spare Kit : 896529/000.
Composition : Guide ring, seals, valve and lubricant.
(!) There is a blue sticker on the gas spring body when it is inflated with a special pressure (<18 MPa)
