RGT 6600 gas spring

• Diameter from 32 to 150 mm
• Stroke from 10 to 125 mm
• Force : from 350 to 9500 daN (9.5t)
• Designed especially for car makers
• Solid design (no welding)
• Design and features similar to RGP but can be used with standard G 1/8’’ piping system (except RGT 350)
• Long bottom threads recommended for fixtures with screws in the upper die
• Conforms to Toyota standard : SMS DNH 3203 N

Print this sheet
RGT 6600 gas spring : HIGH POWER RGT GAS SPRINGS - Quiri - 2
RGT 6600 gas spring : HIGH POWER RGT GAS SPRINGS - Quiri - 3
RGT 6600 gas spring : HIGH POWER RGT GAS SPRINGS - Quiri - 4
RGT 6600 gas spring : HIGH POWER RGT GAS SPRINGS - Quiri - 5
Type Force Stroke C Reference Pressure Force F1 Force F2 LR LC Mass 3D Model
daN mm MPa (bar) N* N* mm mm Kg
RGT 6600 16 443684/000-S 15

(150)

(!)

66 270 95 130 104 88 6,07 3D
19 443685/000-S 97 170 110 91 6,27 3D
25 443686/000-S 100 230 122 97 6,60 3D
32 443687/000-S 102 640 136 104 6,77 3D
38 443688/000-S 104 230 148 110 7,07 3D
50 443689/000-S 106 480 172 122 7,70 3D
63 443690/000-S 108 040 198 135 8,17 3D
75 443691/000-S 109 020 222 147 8,70 3D
80 443692/000-S 109 360 232 152 9,07 3D
100 443693/000-S 110 490 272 172 9,90 3D
125 443694/000-S 114 320 322 197 11,20 3D

* (N) = Kgf x 9.80665 | (Kgf)=N x 0.101972 | 1daN=1 x 101N | 1bar=1 x 10-1MPa

Example of order : RGT 6600 C50
Spare Kit : 896561/000
Composition : Guide ring, seals, valve and lubricant.

RGT 6600 gas spring : HIGH POWER RGT GAS SPRINGS - Quiri - 6

(!) There is a blue sticker on the gas spring body when it is inflated with a special pressure (<15 MPa)
