RGH 1500 gas spring
| Type | Force
daN |
Stroke C
mm |
Order code | Pressure
MPa (bar) |
Force F1
N * |
Force F2
N * |
LR
mm |
LC
mm |
Weight
Kg |
| RGH | 1500 | 25 | 442561/000 | 15
(150) |
15 270 | 21 590 | 110 | 85 | 2.70 |
| 38.1 | 442562/000 | 21 670 | 136.2 | 98.1 | 2.80 | ||||
| 50 | 442563/000 | 21 800 | 160 | 110 | 2.90 | ||||
| 63.5 | 442564/000 | 21 720 | 187 | 123.5 | 3.00 | ||||
| 80 | 442565/000 | 21 830 | 220 | 140 | 3.20 | ||||
| 100 | 442566/000 | 21 830 | 260 | 160 | 3.40 |
* (N) = Kgf x 9.80665 | (Kgf)=N x 0.101972 | 1daN=1 x 101N | 1bar=1 x 10-1MPa
Example of order: RGH 1500 C50
Spare Kit : 896521/000.
Composition : Guide ring, seals, valve and lubricant.
