RGH 5000 gas spring
| Type | Force | Stroke C | Reference | Pressure | Force F1 | Force F2 | LR | LC | Mass |
| daN | mm | MPa (bar) | N* | N* | mm | mm | Kg | ||
| RGH | 5000 | 25 | 442961/000 | 15
(150) |
49 780 | 73 930 | 140 | 115 | 8.20 |
| 38.1 | 442962/000 | 74 800 | 166.2 | 128.1 | 8.60 | ||||
| 50 | 442963/000 | 75 430 | 190 | 140 | 8.90 | ||||
| 63.5 | 442964/000 | 75 420 | 217 | 153.5 | 9.30 | ||||
| 80 | 442965/000 | 76 130 | 250 | 170 | 9.70 | ||||
| 100 | 442966/000 | 76 290 | 290 | 190 | 10.30 |
* (N) = Kgf x 9.80665 | (Kgf)=N x 0.101972 | 1daN=1 x 101N | 1bar=1 x 10-1MPa
Example of order : RGH 5000 C50
Spare kit : 896523/000
Composition : Guide ring, seals, valve and lubricant.
