LOW PROFILE RGH GAS SPRINGS
Other products
Access LOW PROFILE RGH GAS SPRINGS 's products
Access selection
Back to Gas Springs
RGH 750
| Type | Force
daN |
Stroke C
mm |
Order code | Pressure
MPa (bar) |
Force F1
N* |
Force F2
N* |
LR
mm |
LC
mm |
Weight
Kg |
| RGH | 750 | 6 | 442361/000 | 15
(150) |
7 370 | 10 450 | 62 | 56 | 0.65 |
| 12.7 | 442362/000 | 11 280 | 75.4 | 62.7 | 0.68 | ||||
| 19 | 442363/000 | 11 260 | 88 | 69 | 0.71 | ||||
| 25 | 442364/000 | 11 350 | 100 | 75 | 0.74 | ||||
| 38 | 442365/000 | 11 500 | 126 | 88 | 0.80 | ||||
| 50 | 442366/000 | 11 640 | 150 | 100 | 0.85 | ||||
| 63 | 442367/000 | 11 370 | 176 | 113 | 0.91 | ||||
| 80 | 442368/000 | 11 650 | 210 | 130 | 0.98 | ||||
| 100 | 442369/000 | 11 740 | 250 | 150 | 1.07 | ||||
| 125 | 442370/000 | 11 820 | 300 | 175 | 1.18 |
* (N) = Kgf x 9.80665 | (Kgf)=N x 0.101972 | 1daN=1 x 101N | 1bar=1 x 10-1MPa
Example of order : RGH 750 C50
Spare kit : 896519/000
Composition : Guide ring, seals, valve and lubricant.
